HL1500 Ruggedized Serially-controlled TDR

DISCONTINUED

THIS PRODUCT HAS BEEN DISCONTINUED. EXISTING CUSTOMERS SHOULD CONTACT HYPERLABS FOR SUPPORT.

The HL1500 is a ruggedized time domain reflectometer (TDR) designed for measuring electrical impedance in a variety of test systems.

It generates a stimulus pulse with a 200 ps risetime and 14 µs duration, and takes samples from the incident pulse and the signal reflected from the device under test.

This instrument is controlled via a serial (RS232) connection. The included TDR100 software allows operators to read and process test results on Windows PCs.
